Product Description
The trusses come in sections, ranging from about 2 to 10 feet long, which interlock to span the required distance up to a maximum of about 60 to 75 feet, depending on the particular machine. The truss sections can be set at an angle to produce crowned or invert profiles.
By hand-operated winches typically serve to propel the truss screed along the edge forms and across the surface. Hydraulic-powered truss screeds can move at variable speeds, some up to 24 feet per minute.
Engine driven truss screed
DESCRIPTION | KVTS |
FRAME CONSTRUCTION | STEEL |
VIBRATION SYSTEM | ECCENTRIC SHAFT |
ENGINE ( WIDTHS LESS THAN 50’) | HONDA GX270 - 9 HP (6.7KW) |
ENGINE ( WIDTHS MORE THAN 50’) | HONDA GX340 - 11 HP (8.2 KW) |
SECTION LENGTHS/WEIGHTS |
|
2 FT (610MM) | 37 LB (17 KG) |
2.5 FT (760MM) | 46 LB (20 KG) |
5 FT (1500MM) | 90 LB (41 KG) |
7.5 FT (2300MM) | 135 LB (61 KG) |
10 FT (3100MM) | 180 LB (82 KG) |
MAXIMUM WIDTH | 65 FT 19800MM |
LOWEST CONCRETE SLUMP | 3 INCH (76 MM) |
BLADES | 10 INCH (254 MM) |
ELECTRIC MOTOR DRIVEN TRUSS SCREED
DESCRIPTION | KVTS |
FRAME CONSTRUCTION | STEEL |
VIBRATION SYSTEM | ECCENTRIC SHAFT |
ENGINE ( WIDTHS LESS THAN 50’) | 10 HP , 3PH, 440 VOLT AC |
ENGINE ( WIDTHS MORE THAN 50’) | 15 HP, 3 PH, 440 VOLT AC |
SECTION LENGTHS/WEIGHTS |
|
2 FT (610MM) | 37 LB (17 KG) |
2.5 FT (760MM) | 46 LB (20 KG) |
5 FT (1500MM) | 90 LB (41 KG) |
7.5 FT (2300MM) | 135 LB (61 KG) |
10 FT (3100MM) | 180 LB (82 KG) |
MAXIMUM WIDTH | 65 FT 19800MM |
LOWEST CONCRETE SLUMP | 3 INCH (76 MM) |
BLADES | 10 INCH (254 MM) |
